The working principle of three cone drilling tools is based on their special structure. When the drilling rig drives the drilling tool to rotate, the three teeth form a continuous cutting motion, which efficiently cuts and breaks the formation. At the same time, the pressure transmitted through the drill pipe allows teeth to penetrate deep into the formation, forming the required wellbore or hole. In addition, the drilling tool is equipped with a coolant circulation system to reduce the heat generated by friction between the drill bit and the wellbore, protect the drill bit and cutting teeth, and extend their service life.
SIZE | 6inch(152.4mm) |
IADC | 617 |
G | gauge protection |
Thread | 3 1/2"REG PIN |
Bearing | rubber sealed bearing |
WOB(KN/mm) | 0.35-1.05 |
RPM(r/min) | 80-40 |
Application formation | medium hard with high compressive strength and thick&hard
stringers,such as hard shale,limestone,sandstone and dolomite,etc. |
Crossing Bit, a leading manufacturer of PDC bits and tricone bits in northern China, has exported its high-quality drill bits to more than 30 countries, demonstrating its strong market influence and exceptional product strength.
Crossing Drilling Tools has not only established a sterling reputation in the drilling, construction, HDD (horizontal directional drilling), exploration, water well, geothermal, mining, and oil & gas industries, but has also gained widespread recognition from customers for its exceptional product reliability and quality. We are committed to developing and producing a range of high-quality tools, including tricone bits, PDC bits, tricone cutters (single rollers), PDC reamers, drag bits, and HDD hole openers, to meet the diverse needs of our customers.
Our meticulously designed PDC bits are specifically optimized for directional drilling. With exceptional stability, durability, and "directional" friendliness, they are able to precisely maintain the bit's position in narrow and complex pay zones, ensuring smooth drilling operations.
This unique steerable bit technology, combined with high ROP (rate of penetration), sets Crossing Bit apart from the competition and establishes it as a leader in the industry.
|
|
